系列参数机型CG28DGIIICG30DGIIICG32DGIII国三电控单缸水冷柴油机动力类型/Power type单缸，水冷，四冲程，卧式/Single cylinder,Water-cooled,Four stoke,Horizontal type燃烧室型式/Combustion chamber type直喷/Direct injection缸径(mm)/Cylinder Bore125130130行程(mm)/Piston stroke120125排量(L)/Displacement1.473&
| 系列 | 参数 | 机型 | ||
| CG28DGIII | CG30DGIII | CG32DGIII | ||
| 国三电控单缸水冷柴油机 | 动力类型/Power type | 单缸，水冷，四冲程，卧式/Single cylinder,Water-cooled,Four stoke,Horizontal type | ||
| 燃烧室型式/Combustion chamber type | 直喷/Direct injection | |||
| 缸径(mm)/Cylinder Bore | 125 | 130 | 130 | |
| 行程(mm)/Piston stroke | 120 | 125 | ||
| 排量(L)/Displacement | 1.473 | 1.593 | 1.659 | |
| 压缩比/Compression ratio | 17 | 16 | ||
| 额定转速(rpm)/Rated speed | 2200 | |||
| 额定功率(kw)/Rated power | 18.38 | 20.1 | 22 | |
| 额定功率(hp)/Rated power | 25.00 | 27.34 | 29.92 | |
| 最大扭矩（N.m)/Max torque | 91.75 | 100.34 | 109.83 | |
| 最大扭矩点转速（r/min）/Speed at Max torque point | 1650 | 1650 | 1650 | |
| 标定点燃油耗（g/kw.h）/Fuel consumption | 244.8 | 254.4 | ||
| 起动方式/Start mode | 电起动/eletric start | |||
| 燃油牌号/Fuel number | 柴油：0#（夏）-10（冬）Fuel:0#（Summer),-10(Winter) | |||
| 机油牌号/Oil number | SAE10W30(CD级以上) | |||
| 外形尺寸（长*宽*高）（mm）/Overall dimension | 900*465*745 | 982×497×714 | ||
| 净重（kg）Net weight | 195 | 200 | 215 | |
