系列参数机型R(Z)185R(Z)190CGZ12CGZ13CG14CG16水冷单缸柴油机动力类型/Power type单缸，水冷，四冲程，卧式/Single cylinder,Water-cooled,Four stoke,Horizontal type燃烧室型式/Combustion chamber type涡流（直喷）/Whirling (Direct injection)排量(L)/Displacement0.5110.5730.5980.6730.695
| 系列 | 参数 | 机型 | |||||
| R(Z)185 | R(Z)190 | CGZ12 | CGZ13 | CG14 | CG16 | ||
| 水冷单缸柴油机 | 动力类型/Power type | 单缸，水冷，四冲程，卧式/Single cylinder,Water-cooled,Four stoke,Horizontal type | |||||
| 燃烧室型式/Combustion chamber type | 涡流（直喷）/Whirling (Direct injection) | ||||||
| 排量(L)/Displacement | 0.511 | 0.573 | 0.598 | 0.673 | 0.695 | 0.785 | |
| 压缩比/Compression ratio | 19 | ||||||
| 额定转速(rpm)/Rated speed | 2200 | 2400 | |||||
| 额定功率(kw)/Rated power | 5.88 | 7 | 8 | 8.8 | 9.1 | 10.2 | |
| 额定功率(hp)/Rated power | 8.00 | 9.52 | 10.88 | 11.97 | 12.38 | 13.87 | |
| 最大功率( KW)/Max power | 6.47 | 7.70 | 8.80 | 9.68 | 10.01 | 11.22 | |
| 最大功率 (HP)/Max power | 8.80 | 10.47 | 11.97 | 13.16 | 13.61 | 15.26 | |
| 最大扭矩（N.m)/Max torque | 29.35 | 34.94 | 39.94 | 43.93 | 45.43 | 50.92 | |
| 最大扭矩点转速（r/min）/Speed at Max torque point | 1650 | 1650 | 1650 | 1650 | 1650 | 1650 | |
| 标定点燃油耗（g/kw.h）/Fuel consumption | 252 | 245 | 240 | ||||
| 起动方式/Start mode | 手摇或电起动/Hand start or eletric start | ||||||
| 燃油牌号/Fuel number | 柴油：0#（夏）-10（冬）Fuel:0#（Summer),-10(Winter) | ||||||
| 机油牌号/Oil number | SAE10W30(CD级以上) | ||||||
| 外形尺寸（长*宽*高）（mm）/Overall dimension | 670×378×560 | 730×390×570 | |||||
| 净重（kg）Net weight | 95 | 100 | 102 | ||||
